Power supply 24 VAC −10%, +20%, 50…60 Hz
Power supply 24 VDC −20%…+20%
Power consumption during opera
tion1)
1.2 W
Start-up current < 320 mA after max. 2 minutes
Parameters
Stroke2) 6.5 mm
Closing force 125 N +5%
Running time3) 30 s/mm
Control signal 0…10 V
Control signal input resistance 100 kΩ
Position feedback signal 0…10 V (0.1 V resolution)
Position feedback signal output impe
dance
10 kΩ
Position feedback signal output cur
rent
0.1 mA (1 mA if shorted)
Output load impedance 100 kΩ…1000 kΩ
Ambient conditions
Ambient temperature 0…50 °C
Storage and transport temperature −25…60 °C
Operating temperature at valve Max. 100 °C
Air humidity < 85% rh, no condensation
Construction
Housing White (RAL 9003), surface structured
according to VDI 3400 Ref. 27
Housing material Polyamide
Power cable4) Ø 0.22 mm², 3- or 4-core, signal
white (RAL 9003)
Weight 0.15 kg (without power cable
